QuickTip: Disable cpu-microcode from loading on ESXi
Note
This article is more than 1 year(s) old – information may be outdated.
Just a random quick-tip for labs: Disabling cpu-microcode for better CPU power efficiency – with trade-off being security. By default, ESXi will load the cpu-microcode module shipped with the installation, if it is newer and applicable than what BIOS provides. It is typically updated with regular ESXi updates. This can be disabled.
The VIB installation is like:
[root@esxi01:~] vmware -vl
VMware ESXi 8.0.3 build-24674464
VMware ESXi 8.0 Update 3
[root@esxi01:~] esxcli software vib list | grep microcode
cpu-microcode 8.0.3-0.70.24674464 VMware VMwareCertified 2025-04-29 host
If some performance wants to be regained, at the severe cost of security, cpu-microcode could be removed from the installation. Altought, this is tedious on a longer run and will be re-installed during each update. Hence preventing it from loading in the first place is the best way.
To check the current settings (which are also default as of 8.0 U3):
[root@esxi01:~] esxcli system settings kernel list -o microcodeUpdate
Name Type Configured Runtime Default Description
--------------- ---- ---------- ------- ------- -----------
microcodeUpdate Bool TRUE FALSE TRUE Update microcode from boot module if available
[root@esxi01:~] esxcli system settings kernel list -o microcodeUpdateForce
Name Type Configured Runtime Default Description
-------------------- ---- ---------- ------- ------- -----------
microcodeUpdateForce Bool FALSE FALSE FALSE Disable check that microcode update is newer than installed microcode and that both are released versions
To disable it:
esxcli system settings kernel set -s microcodeUpdate -v FALSE
esxcli system settings kernel set -s microcodeUpdateForce -v FALSE
Then it will look like:
[root@esxi01:~] esxcli system settings kernel list -o microcodeUpdate
Name Type Configured Runtime Default Description
--------------- ---- ---------- ------- ------- -----------
microcodeUpdate Bool FALSE FALSE TRUE Update microcode from boot module if available
During boot time, it can then also be seen that microcode is not loaded anymore:
[root@esxi01:~] zcat /var/log/boot.gz | grep -i microcode
TSC: 393954 cpu0:1)BootConfig: 783: microcodeUpdate = FALSE (0)
TSC: 395993 cpu0:1)BootConfig: 783: microcodeUpdateForce = FALSE (0)
TSC: 398297 cpu0:1)BootConfig: 783: skipMicrocodeCompatCheck = FALSE (0)
0:00:00:00.000 cpu0:1)MicrocodeUpdate: 117: Early microcode patching disabled by boot option
0:00:00:00.000 cpu0:1)MicrocodeUpdate: 257: Microcode Update Signature (MSR 0x8b): 0x0b00003e; Platform ID (MSR 0x17): 0x0
0:00:00:05.570 cpu0:2097152)VMK init (95/192): MicrocodeUpdate_LateCleanup
0:00:00:05.571 cpu0:2097152)SysInitTable: 113: Finished sysInit step: MicrocodeUpdate_LateCleanup in 1023 us.
In this case, the cpu-microcode from BIOS will be loaded and used.
